Specifications:
Power Handling
General Specifications
- Frequency Response: 20 ~ 230Hz
- Sensitivity: : 93dB
- Recommended Enclosure: 0.5 ~ 1.0 Cubic Feet
- Dimensions: 13" x 3-7/8"
- Mounting Depth: 3-1/4"
- Accessory Grill: UD-G308
General Features
- Interlaced Basalt/Carbon Fiber Reinforced IMPP Cone
- Double Cone with Air Suspension Control System
- 3-Layer Fiber Woven Radial Surround with M-shape Cross-section
- Aluminum 6 Layer, Long Voice Coils
- Aluminum Voice Coil Wire
- Phenol Resin Coated Glass Cloth Voice Coil Bobbin
- Air Suspension Control System
- Projected Pole Yoke with Vented Pole
- Strontium Magnet Construction
- Cast Aluminum Basket with Fin-Shaped Design Basket Design
- Rubber Gasket
- Silver Spring Compression Terminals
|
