Specifications:
Power Output
- 60W RMS x 4 @ 4-Ohms
- 125W RMS x 4 @ 2-Ohms
- 250W RMS x 2 @ 4-Ohms bridged
General Features
- 12dB/octave crossover
- 2/4 channel switch
- 4 Gauge power/ground terminals
- Audiophile grade speaker connections
- MOSFET output stage
- MOSFET power supply
- Top Mounted LED Indicators
General Specifications
- Bridgeable
- Signal Input: Low level: 2 RCA pair
- Power Input Connector: Block
- Power Wire Gauge: 4 AWG
- Speaker Output Connector: Screw terminal barrier strip
- Speaker Wire Gauge: 8 AWG to 18 AWG
- Heat Sink Type: Cast aluminum
- Cooling: Convection
- Remote Controls: Optional PEQ Remote Punch EQ
- (overrides built-in Punch EQ2 for rear channels only)
- Visual Indicators: Power, Thermal, Protect
- Circuit Topology Class: Class A/B
- Frequency Response: 20Hz to 20kHz +/- 1.0dB
|
