Specifications:
Rated Power
- 225W RMS x 1 @ 4-Ohms
- 450W RMS x 1 @ 2-Ohms
- 700W RMS x 1 @ 1-Ohm
General Features
- 12dB/octave crossover
- 4 Gauge power/ground terminals
- Audiophile grade speaker connections
- Infrasonic filter
- MOSFET output stage
- MOSFET power supply
- RCA pass-thru
- Top Mounted LED Indicators
- Efficiency (average): 84.7% @ 4-Ohm, 80.5% @ 2-Ohm
- Crossover Controls: High-Pass (LP) - 35Hz-250Hz 12dB/octave Butterworth
- Tone Controls: Punch EQ2 Bass - 0dB to +18dB @ 45Hz
- Signal Input: Low level: 1 RCA pair
- Signal Output: Low level: 1 RCA pair
- Power Input Connector: Block
- Power Wire Gauge: 4 AWG
- Speaker Output Connector: Screw terminal barrier strip
- Speaker Wire Gauge: 8 AWG to 18 AWG
- Heat Sink Type: Cast aluminum
- Cooling: Convection
- Remote Controls:
- Optional PEQ Remote Punch EQ
- (overrides built-in Punch EQ2)
- Visual Indicators: Power, Thermal, Protect
- Circuit Topology Class: Class B/D
- Frequency Response: 20Hz to 250Hz +/- 1.0dB
|
