Specifications:
General Features
- Amplifier Type: Class-D
- Channel Design: 4 Channel + 1 Channel (Mono)
- Thermal Control: Thermal Management Control
- Power Supply: DC-DC PWM Power Supply
- Power Supply Design: Direct FET Power
- Board Circuitry: STAR Circuitry
- Current Protection: Over-Current, Over-Voltage and Thermal Protection
- Power Indicator: Top/Side Mounted LED Power/Status Indicator
- RCA Output: Gold Plated RCA Input Connectors
- Crossover: Adjustable Low-Pass/High-Pass
- Connector Plating: Gold Plated Input, Output, Power and Speaker Terminals
- Pre-Amp Stage: Discrete
- Board Design: Dual Sided Glass Epoxy PC Board
- Gain Control: Continuously Adjustable Gain Control
- Crossover: 30Hz-400Hz, -12dB/oct. (Low-Pass/High-Pass for 4CH), 20Hz-200Hz, -24dB/oct. (Low-Pass for Mono)
- Subsonic Filter: 15Hz (Fixed), -24dB/oct. for Mono
|
