Specifications:
Power Handling
- Nominal Power: 70 Watts
- Peak Power: 210 Watts
General Features
- Frequency Response: 45Hz - 22kHz
- Impedence: 4 ohm
- Sensitivity: 90 dB 1W/1m
Tweeter
- Tweeter Type: Titanium Dome
- Mounting Design: Front Mount Design
- Application Type / Design Detail: Front Mount / Swivel Design
- Magnet Material: Neodymium
Woofer
- Dustcap Detail: Inverted Dustcap
- Cone Material: Poly-Mica Cone
- Motor Technology: Aluminum Shorting Ring
- Voice Coil Type: 1.25'' High-Temp Copper Coil
- Cooling: Optimized Airflow Design
- Magnet: Ferrite
- Mounting: Front Mount / IPX6 Sealed Gasket
- Frame: High Temp ABS Frame
Crossover Network
- Grade: Professional Grade Network
- Case Design: Internal Sealed Design
- Attenuation Control: 0 dB / - 3dB
- Mounting: Integrated into Woofer Frame
Mounting Specifications
- Tweeter Mounting Diameter (mm): 55.3mm
- Tweeter Mounting Diameter (in): 2-6/32''
- Tweeter Mounting Depth (mm): 25mm
- Tweeter Mounting Depth (in): 1''
- Woofer Diameter (mm): 195.9mm
- Woofer Diameter (in): 7-23/32''
- Woofer Mounting Diameter (mm): 162.6mm
- Woofer Mounting Diameter (in): 6-13/32''
- Woofer Mounting Depth (mm): 93.1mm
- Woofer Mounting Depth (in): 3 -31/32''
|
