Specifications:
- 4/3/2 Channel Operation
- 100 watts RMS x 4 at 4 ohms (100 watts RMS x 4 at 2 ohms)
- 200 watts RMS x 2 in bridged mode (4-ohm stable in bridged mode)
- CEA-2006 compliant
- Stackable Installation Design with front-panel controls
- Thermal Management Processor
- Adjustable Crossover (HP/LP)
- MOSFET Power Supply
- DC-DC PWM Power Supply
- MOSFET Final Outputs
- STAR Circuitry
- Auto Over-Current Protection
- Top Mounted Blue LED Power/Status Indicator
- Integrated Wire and Mounting Screw Terminals
- Input Channel Selector
- Input Mode Selector Switch
- One Side Terminal Layout
- Gold Plated RCA Input Connectors
- Continuously Adjustable Gain Control
- Gold Plated Power Screw Terminals
- 4-Layer Glass Epoxy PC Board
- Speaker Quick Connect
- fuse rating: 30A x 2
- 10-3/16"W x 2-1/2"H x 8-1/2"D
|
