Specifications:
- DMA-optimized, long linear excursion capability to virtually eliminate distortion and increase sound output
- Perform outstanding in compact sealed or ported enclosures
- DMA (Dynamic Motor Analysis) modeling to deliver unsurpassed dynamic stability and low-distortion operation within intended power range
- Mineral-filled polypropylene upper cone with a metallic JL Audio medallion logo gives the W3's a whole new, classy and sophisticated look
- Vented Reinforcement Collar
- Insert Molded Suspension / Coil / Terminal Sub-Assembly
- Customizable Trim Ring
- Elevated Frame-Cooling
- Floating Cone Attach Method
- Surround Stress-Relief
- Free Air Resonance (Fs): 26.72 Hz
- Electrical "Q" (Qes): 0.472
- Mechanical "Q" (Qms): 7.572
- Total Speaker "Q" (Qts): 0.444
- Equivalent Compliance (Vas): 2.844 cu. ft. / 80.54 liters
- One-Way, Linear Excursion (Xmax): 0.510 in. / 13.0 mm
- Reference Efficiency (no): 0.313%
- Efficiency (1W/1m): 87.15 dB SPL
- Effective Piston Area (Sd): 80.600 sq. in. / 0.0520 sq. m.
- DC Resistance (Re): 3.563 ohm
- Nominal Impedance (Znom): 4 ohm
- Thermal Power Handling (Pt): 300W
- Driver Displacement: 0.071 cu. ft. / 2.01 liters
- Net Weight: 14.50 lbs. / 6.58 kg
- Priced per speaker
|
