Specifications:
- 1x150Watts RMS at 4 Ohms
- 1x250Watts RMS at 2 Ohms
- 1x400Watts RMS at 1 Ohms
- 1x700 Watts Max at 2 Ohms Bridged
- 1 Ohm Stable
- MOSFET Power Supply
- PWM(Pulse-Width-Modulated) System
- Bi-Ampable Strapping
- Glass Epoxy PCB
- Gold Plated RCA Inputs/Line outs
- Input sensitivity : 200mV~8V
- Variable Low Pass Filter : 50Hz~150Hz 24dB/Octave
- Variable Subsonic Filter : 15Hz~40Hz 24dB/Octave
- Variable Bass Boost Control : 0~+18dB
- Phase Control 0~180 degree
- THD : 0.1%
- S/N Ratio : 90dB
- Remote Subwoofer Bass Control
- Frequency Response : 15Hz~150Hz
- Input Impedance : 10K Ohms
- Heavy Duty Power Coated Heatsink
- Custom Terminal Block for Speaker Connections
- Thermal, Overload & Short Protection
- Soft Turn-on/Turn-off
- Dimensions : 10.25"(W) x 2.36"(H) x 10"(L)
|
