Specifications:
- OUTPUT (WATTS):RMS @ 4 Ohms 85x2
- RMS @ 2 Ohms 170x2
- RMS Bridged @ 4 Ohms 340 X 1
- T.H.D.: < 0.02%
- Frequency Response (Hz): 10 - 50K
- SIGNAL TO NOISE RATIO: > 100dB
- DAMPING FACTOR: > 300
- INPUT SENSITIVITY: 0.10 - 8.0
- CROSOVER SLOPE: 12dB
- CROSSOVER FREQUENCY (HZ): 50Hz - 250kHz
- DIMENSIONS (INCHES): 8.75x2x8.75”
- Input sensitivity: 100mV - 2V or 2V - 8V
- Variable bass boost: 0 to +12dB
- Trimode capable
- Variable 18dB high & low pass crossover
- Low level inputs
- Low level outputs
- High speed digital circuitry
- Fully regulated PWM power supply
- Four way protection circuit
- Dash mount bass knob remote
- Marine coated circuit board
- All chrome plated
|
