Specifications:
- Master volume control with up to 10 volts RMS of output
- Front/rear fader control
- Four band parametric equalizer with 18dB boost per Cut.
- Variable bandwidth for each band
- Low noise Bi-Fet op-amp design yields
- minimum distortion
- 30V bi-polar switching power supply
- Subwoofer output and level control
- Subwoofer frequencies adjustable 50Hz-250Hz
- AUX/CD input selector
- Universal half-Din chassis for ease of installation
- Gold-plated RCA input/output connectors
- 20dB headroom eliminateas signal overload
- 4 band parametric range: Sub 20-70Hz/ Low 150-400Hz/Mid 1.5-4KHz/HI 4-20KHz
- Subwoofer Crossover: 50-250Khz
- Boost/Cut: 18dB
- S/N Ratio: >120dB Ref 1V Input
- Frequency Response: 10Hz-15KHz, + / -1dB
- Stereo Separation: 90dB/1KHz
- Maximum Output Volage: 10V RMS
- THD: <0.005%
- Headroom: >20dB
- Input Impedance: >50k Ohm
- Output Impedance: <10K Ohm
|
